최첨단 Magellan Navigation System은 로봇 스스로 풀의 폭 및 길이를 측정하고 면적을 계산하여 가로 및 세로 방향으로 중복되지 않고 정확하게 완벽한 두 번의 청소를 수행한다.

Time Limit 설정 기능으로 장애물이나 경사진 바닥, 다양한 모양의 수영장에서도 매우 효과적으로 안전하고 강력하게 최단시간 내에 청소기능을 수행한다.

각각 모양이 다른 4개의 수영장, 또는 4가지의 청소방식을 설정하여 청소할 수 있는 기능 탑재 (선택사항)

청소 진행 정도를 알 수 있는 표시기가 장착되어 있다.

손 쉬운 필터 청소

스테인레스 케이블드럼 및 핸들장착으로 케이블의 정리가 간편하다.

납품일로부터 2년간의 완벽한 품질보증 (소모성 부품 제외)






Technical Data
;


Suction width 510 mm
Weight in water
out of water
3.3kg / 21kg
Trolley Stainless steel with cable reel
Floating cable length 32m
Power supply 220-110 VAC/24 VDC
Pump capacity 50m3/h
Filtration Filter bag 20, 105, or 250 microns
Remote control Waterproof, 8 functions
Brushing Mixt PVC/PVA brushes
Speed-Cleaning per SQM 15m/mn-367 m²/h
Minimum depth 35 cm
Magellan navigation +
Gyroscope
Magellan crosses, H, V mode automatic Manual control
Wall and obstacles detection With 4 infrared eyes, tilt & level sensor No water detection
Unit size 510 X 400 X 350 mm
